Intel 4004

E29765

The Intel 4004 is the first commercially available microprocessor, a 4-bit CPU introduced in 1971 that launched the microprocessor revolution.

AI illustration

How this image was made

AI-generated illustration of Intel 4004

This AI-generated illustration was produced by black-forest-labs/FLUX.2-dev (1024x1024) from a prompt written by openai/gpt-oss-120b from the entity's label + description.

Prompt

Generate an image of the Intel 4004 (The Intel 4004 is the first commercially available microprocessor, a 4-bit CPU introduced in 1971 that launched the microprocessor revolution.)

All labels observed (11)

How this entity was disambiguated

Statements (48)

Predicate Object
instanceOf 4-bit microprocessor ⓘ
central processing unit ⓘ
microprocessor ⓘ
addressBusWidth 12-bit ⓘ
announced November 1971 ⓘ
architecture Harvard architecture ⓘ
bitSlice serial 4-bit data path ⓘ
canAddress up to 16 registers ⓘ
clockSpeed 740 kHz ⓘ
coDesigner Marcian Hoff ⓘ
Masatoshi Shima ⓘ
Stanley Mazor ⓘ
companyCountry United States ⓘ
dataBusWidth 4-bit ⓘ
designLead Federico Faggin ⓘ
dieSize 12 mm² ⓘ
fabricationMaterial silicon ⓘ
fabricationProcess silicon-gate MOS technology ⓘ
family Intel MCS-4 ⓘ
linked to: Intel 4004
hasALU 4-bit ALU ⓘ
hasBCDSupport yes ⓘ
instructionCycleTime 10.8 µs ⓘ
instructionSetSize 46 instructions ⓘ
instructionType binary-coded decimal oriented ⓘ
introduced 1971 ⓘ
manufacturer Intel ⓘ
linked to: Intel Corporation
marketedAs first commercially available microprocessor ⓘ
maximumAddressableDataMemory 640 bytes ⓘ
maximumAddressableMemory 4096 bytes ⓘ
maximumAddressableProgramMemory 4 KB ⓘ
maximumInstructionsPerSecond ~92,000 instructions per second ⓘ
notableFor launching the microprocessor revolution ⓘ
onChipStackDepth 3 levels ⓘ
originalApplication calculator ⓘ
originalCustomer Busicom ⓘ
packageType 16-pin dual in-line package ⓘ
partOfChipset Intel 4001 ROM ⓘ
Intel 4002 RAM ⓘ
Intel 4003 shift register ⓘ
powerSupplyVoltage 15 V ⓘ
status discontinued ⓘ
successor Intel 4040 ⓘ
linked to: Intel 4004

Intel 8008 ⓘ
supportsInterrupts no ⓘ
supportsSubroutines yes ⓘ
technologyNode 10 µm ⓘ
transistorCount 2300 ⓘ
wordLength 4-bit ⓘ

How these facts were elicited

Referenced by (32)

Full triples — surface form annotated when it differs from this entity's canonical label.

Intel Corporation → notableProduct → Intel 4004 ⓘ
Intel 4004 → family → Intel MCS-4 ⓘ
linked to: Intel 4004
Intel 4004 → successor → Intel 4040 ⓘ
linked to: Intel 4004
Intel Museum → hasExhibit → Intel 4004 microprocessor ⓘ
linked to: Intel 4004
Federico Faggin → notableWork → Intel 4004 ⓘ
Federico Faggin → designed → Intel 4004 ⓘ
Marcian Hoff → notableWork → Intel 4004 ⓘ
Busicom → commissioned → Intel 4004 ⓘ
Busicom → usedMicroprocessor → Intel 4004 ⓘ
Intel 4001 → partOf → Intel MCS-4 microprocessor family ⓘ
subject linked to: Intel 4001 ROM
linked to: Intel 4004
Intel 4001 → designedFor → Intel 4004 microprocessor ⓘ
subject linked to: Intel 4001 ROM
linked to: Intel 4004
Intel 4001 → usedWithCPU → Intel 4004 ⓘ
subject linked to: Intel 4001 ROM
Intel 4001 → associatedChipFamily → Intel 4004 CPU ⓘ
subject linked to: Intel 4001 ROM
linked to: Intel 4004
Intel 4003 → usedWith → Intel 4004 ⓘ
subject linked to: Intel 4003 shift register
Intel 4003 → family → Intel MCS-4 family ⓘ
subject linked to: Intel 4003 shift register
linked to: Intel 4004
Intel 4003 → introducedWith → Intel 4004 microprocessor set ⓘ
subject linked to: Intel 4003 shift register
linked to: Intel 4004
Stanley Mazor → notableWork → Intel 4004 ⓘ
Stanley Mazor → memberOf → Intel 4004 design team ⓘ
linked to: Intel 4004
Intel 4002 → partOf → Intel 4004 microprocessor chipset ⓘ
subject linked to: Intel 4002 RAM
linked to: Intel 4004
Intel 4002 → designedFor → Intel 4004 microprocessor ⓘ
subject linked to: Intel 4002 RAM
linked to: Intel 4004
Intel 4002 → introducedWith → Intel 4004 ⓘ
subject linked to: Intel 4002 RAM
Intel 8008 → predecessor → Intel 4004 ⓘ
Masatoshi Shima → notableWork → Intel 4004 ⓘ
Masatoshi Shima → designed → Intel 4004 ⓘ
MCS-4 → includes → Intel 4004 ⓘ
MCS-4 → hasCentralProcessingUnit → Intel 4004 ⓘ
Intel 4040 → predecessor → Intel 4004 ⓘ
Intel 4040 → compatibleWith → Intel 4004 ⓘ
Ted Hoff → knownFor → Intel 4004 ⓘ
Ted Hoff → designed → Intel 4004 architecture ⓘ
linked to: Intel 4004
PL/M → designedFor → Intel 4004 ⓘ
subject linked to: PL/M programming language
