10BASE5
E81124
10BASE5 is the original thick coaxial Ethernet standard that operated at 10 Mbps over relatively long cable runs and formed the basis of early wired local area networks.
All labels observed (2)
How this entity was disambiguated
This entity first appeared as the object of triple T638007 — resolving that mention is where its identity was fixed. The disambiguator weighed these candidate entities and picked the highlighted one (or “None”, minting a new entity). This is how homonymy is resolved: the same surface form can point to different entities.
NED1
Entity disambiguation (via context triple)
gpt-5-mini-2025-08-07
Target entity: 10BASE5 Context triple: [10BASE2, predecessor, 10BASE5]
-
A.
10BASE2
10BASE2 is an older Ethernet standard that uses thin coaxial cable to provide 10 Mbps networking over relatively short distances in a bus topology.
-
B.
10BASE-T
10BASE-T is an early Ethernet standard that transmits data at 10 Mbps over twisted-pair copper cabling using a star topology.
-
C.
10BASE-FL
10BASE-FL is an Ethernet standard for 10 Mbps data transmission over fiber-optic cabling, commonly used for longer-distance network links.
-
D.
100BASE‑TX
100BASE‑TX is a Fast Ethernet standard that delivers 100 Mbps data transmission over twisted-pair copper cabling, commonly used in local area networks.
-
E.
100BASE-FX
100BASE-FX is a Fast Ethernet standard that uses fiber-optic cabling to provide 100 Mbps full-duplex or half-duplex network connections over longer distances than copper-based variants.
- F. None of above. chosen
- G. Unsure - the case is ambiguous/there is not enough information to decide.
NED2
Entity disambiguation (via description)
gpt-5-mini-2025-08-07
Target entity: 10BASE5 Target entity description: 10BASE5 is the original thick coaxial Ethernet standard that operated at 10 Mbps over relatively long cable runs and formed the basis of early wired local area networks.
-
A.
10BASE2
10BASE2 is an older Ethernet standard that uses thin coaxial cable to provide 10 Mbps networking over relatively short distances in a bus topology.
-
B.
10BASE-T
10BASE-T is an early Ethernet standard that transmits data at 10 Mbps over twisted-pair copper cabling using a star topology.
-
C.
10BASE-FL
10BASE-FL is an Ethernet standard for 10 Mbps data transmission over fiber-optic cabling, commonly used for longer-distance network links.
-
D.
100BASE‑TX
100BASE‑TX is a Fast Ethernet standard that delivers 100 Mbps data transmission over twisted-pair copper cabling, commonly used in local area networks.
-
E.
100BASE-FX
100BASE-FX is a Fast Ethernet standard that uses fiber-optic cabling to provide 100 Mbps full-duplex or half-duplex network connections over longer distances than copper-based variants.
- F. None of above. chosen
Statements (47)
| Predicate | Object |
|---|---|
| instanceOf |
Ethernet physical layer standard
ⓘ
IEEE 802.3 standard ⓘ |
| accessMethod |
CSMA/CD
ⓘ
linked to:
CSMA
|
| alsoKnownAs |
10BASE-5
ⓘ
linked to:
10BASE5
thick Ethernet ⓘ thicknet ⓘ |
| cableType | thick coaxial cable ⓘ |
| collisionDetectionMethod | voltage level monitoring on the coaxial bus ⓘ |
| collisionDomain | entire segment is a single collision domain ⓘ |
| dataRate | 10 Mbit/s ⓘ |
| doesNotSupport | full-duplex operation ⓘ |
| encoding | Manchester encoding ⓘ |
| impedance | 50 ohms ⓘ |
| introduced | 1980s ⓘ |
| layer | OSI layer 1 ⓘ |
| maximumCableDiameter | approximately 10 mm ⓘ |
| maximumNetworkSpanWithRepeaters | 2500 meters (typical 802.3 rule) ⓘ |
| maximumNodesPerSegment | 100 ⓘ |
| maximumRepeaterCount | 4 repeaters between two stations (typical 802.3 rule) ⓘ |
| maximumSegmentLength | 500 meters ⓘ |
| medium | coaxial cable ⓘ |
| minimumNodeSpacing | 2.5 meters ⓘ |
| nameMeaning |
10 for 10 Mbit/s
ⓘ
5 for 500 meter maximum segment length ⓘ BASE for baseband signaling ⓘ |
| physicalMediumDependentSubtype | 10BASE5 PMD ⓘ |
| powerFeeding | transceiver powered from attached station via AUI ⓘ |
| replacedBy |
10BASE-T
ⓘ
10BASE2 ⓘ |
| requires |
grounding at one end of the cable
ⓘ
proper cable termination to avoid reflections ⓘ terminators at both ends of the bus ⓘ transceiver for each attached station ⓘ |
| segmentRole | shared medium for multiple hosts ⓘ |
| segmentType | backbone segment ⓘ |
| specifiedIn | original Ethernet specification ⓘ |
| standardizedIn |
IEEE 802.3
ⓘ
linked to:
IEEE 802.3 Ethernet standard
|
| status | obsolete ⓘ |
| supports | half-duplex operation ⓘ |
| topology | bus topology ⓘ |
| usedFor | early local area networks ⓘ |
| uses |
vampire taps to connect transceivers to the cable
ⓘ
yellow-jacketed coaxial cable in many implementations ⓘ |
| usesConnectorType |
N connector (for cable ends)
ⓘ
vampire tap (for transceiver attachment) ⓘ |
| usesTransceiverAttachment | AUI ⓘ |
| wasCommonIn | early corporate LAN backbones ⓘ |
