drift tube linac (DTL)

E9292

A drift tube linac (DTL) is a type of linear particle accelerator that uses a series of electrically driven drift tubes to progressively increase the energy of charged particle beams.

AI illustration

How this image was made

AI-generated illustration of drift tube linac (DTL)

This AI-generated illustration was produced by black-forest-labs/FLUX.2-dev (1024x1024) from a prompt written by openai/gpt-oss-120b from the entity's label + description.

Prompt

Generate an image of a drift tube linac (DTL) (A drift tube linac (DTL) is a type of linear particle accelerator that uses a series of electrically driven drift tubes to progressively increase the energy of charged particle beams.)

All labels observed (3)

How this entity was disambiguated

Statements (49)

Predicate Object
instanceOf linear particle accelerator ⓘ
radio-frequency linear accelerator ⓘ
accelerates charged particles ⓘ
heavy ion beams ⓘ
ion beams ⓘ
proton beams ⓘ
fieldConfiguration axial electric field in gaps ⓘ
hasAbbreviation DTL ⓘ
hasAdvantage efficient acceleration at low beta ⓘ
relatively simple mechanical structure ⓘ
hasDesignFeature cell length increases with particle velocity ⓘ
drift tubes shield particles from decelerating RF fields ⓘ
standing-wave RF mode ⓘ
synchronous phase operation ⓘ
hasFunction bunch charged particles ⓘ
focus particle beams ⓘ
increase particle beam energy ⓘ
hasLimitation large physical size at high energies ⓘ
less efficient at high particle velocities ⓘ
hasMedium vacuum ⓘ
hasSection accelerating gap ⓘ
drift tube section ⓘ
tank ⓘ
isFollowedBy coupled cavity linac ⓘ
superconducting linac sections ⓘ
isOptimizedFor low to medium energy beams ⓘ
isPrecededBy radio-frequency quadrupole ⓘ
isUsedIn cancer therapy accelerators ⓘ
ion implantation facilities ⓘ
materials science experiments ⓘ
medical accelerators ⓘ
nuclear physics research ⓘ
proton accelerator facilities ⓘ
radioactive ion beam facilities ⓘ
spallation neutron sources ⓘ
operatesIn continuous wave mode ⓘ
pulsed mode ⓘ
requires high-power RF source ⓘ
high-vacuum system ⓘ
precise RF phase control ⓘ
typicalApplication injector for high-energy synchrotrons ⓘ
typicalEnergyRange a few MeV to several tens of MeV ⓘ
usesComponent drift tube ⓘ
usesField radio-frequency electric field ⓘ
usesFocusingElement quadrupole lens inside drift tubes ⓘ
quadrupole magnet ⓘ
usesFrequencyRange tens to hundreds of megahertz ⓘ
usesStructure resonant cavity ⓘ
wasDevelopedFor early proton accelerator applications ⓘ

How these facts were elicited

Referenced by (3)

Full triples — surface form annotated when it differs from this entity's canonical label.

Linac4 → hasComponent → drift tube linac (DTL) ⓘ
Linac4 → hasComponent → cell-coupled drift tube linac (CCDTL) ⓘ
linked to: drift tube linac (DTL)
DTL → fullName → Drift Tube Linac ⓘ
linked to: drift tube linac (DTL)
